Type | Material | Condensate discharge | Assembly method | X x Z x Y (mm) | Additional options |
---|---|---|---|---|---|
straight, box | stainless steel 1.4301 | yes | wall | 1500 x 450 | A two rows of labyrinth filters made of stainless steel 1.4301 B lighting C fan |
Product No. * | Width | Dimensions of filters | Number of filters | Weight (kg) |
---|---|---|---|---|
WGO310 | 1000 | 500 x 400 | 4 | 56 |
WGO312 | 1200 | 500 x 500 | 4 | 65 |
WGO314 | 1400 | 500 x 400 | 6 | 74 |
WGO316 | 1600 | 500 x 500 | 6 | 83 |
WGO318 | 1800 | 500 x 400 | 8 | 92 |
WGO320 | 2000 | 500 x 400 | 8 | 101 |
WGO322 | 2200 | 500 x 500 | 8 | 110 |
WGO324 | 2400 | 500 x 500 | 8 | 119 |
WGO326 | 2600 | 500 x 400 | 12 | 128 |
WGO328 | 2800 | 500 x 500 | 10 | 137 |
WGO330 | 3000 | 500 x 400 | 14 | 146 |
* if you want to order a hood with labyrinth filters, add A to product number * if you want to order a hood with lighting, add B to product number * if you want to order a hood with a fan, add C to product number |
